FSA, BB-EVO8681, BB386, BB Shell: 68mm, Stainless, 200-3201

The FSA MegaEvo BB-EVO8681 (MPN: 200-3201) is a specialized threaded bottom bracket designed to adapt a modern BB386EVO road crankset with a 30mm spindle into a standard 68mm English-threaded (BSA) frame shell.

Technical Specifications

• Frame Interface: British / English Threaded (BSA)
• Frame Shell Width: 68mm (Standard Road)
• Crankset Standard: BB386EVO (30mm spindle with extended length)
• Spindle Diameter: 30mm
• Bearings: Premium, double-sealed Stainless Steel ball bearings for excellent corrosion resistance and longevity.
• Cups: Titanium or Red anodized CNC-machined alloy external cups.
• Electronics Compatibility: Fully compatible with internal wiring systems like Shimano Di2 or Campagnolo EPS.

Compatibility Warning

This bottom bracket is unique because it forces large 30mm spindle bearings outside of a narrow threaded frame shell. As a result, it requires a dedicated MegaEvo installation tool, such as the FSA MegaEvo Cup Spanner or specialized sockets from Wolf Tooth or Park Tool.

Note: Standard Shimano or SRAM external bottom bracket tools will not fit the wider diameter cup notches.

This product is ideal for cyclists seeking high-performance adaptability for their road bike setups, ensuring durability and precision.
